Technical Specifications
Specifications
Technical Standard
Base Substrate IS 15961 & Colour coated as per IS 15965
Grade
550 Mpa or 345 Mpa as per customer's requirement
Thickness
0.3-1.5mm Total Coated Thickness
Width
Up to 1550mm
Al-Zn Coating
150-200 g/m2
Color
all RAL Colors, or according to customers requirements
Paint System
RMP, SMP, SDP & PVDF
Top Side
Primer paint + polyester paint coating (25 microns) min
Back Side
Primer epoxy (10 microns) min
Coil Weight
3-8 tons per coil
Salt Spray Resistance
>=1000 hours with SDP /PVDF Paints.
SRI Value
> = 80 (Subject to Shade Specific)
Paint Properties Comparison
Properties
SUPER/HIGH Durable Polyster
RMP
SMP
PVDF
Flexibility
Good
Fair
Poor
Good
UV Resistance
Good
Poor
Fair
Excellent
Gloss Retention
Excellent
Good
Good
Poor
Chalking Resistance
Good
Poor
Fair
Excellent
Costs
Marginal
Lowest
High
Very High
SST Hrs
1000
750
750
1000
Paint types available
Regular Modified Polyester - RMP
Silicon Modified Polyester - SMP
Super Durable Polyester - SDP
Polyvinylidene Fluoride - PVDF
Learn More »
Performance Testing
Specifications
Scratch Hardness (T/B)
1.5 - 2/1 - 1.5 kg
Impact Test (in Joules) (thickness based soft material)
As per standard
Salt Spray Test (Specific to Coating Type)
750 - 1000 hrs
Adhesive Test (cross-hatch)
100%
Erichsen Cupping Test
As per standard
Humidity Test
750 - 1000 hrs
T-Bend Test (T = substract thickness)
2T for soft. 4T forHard (no tape loss)
Water Boiling Test
As per Standard
Solvent Rub Test (MEK - double rub)
> 100DR For Non Metalic, 80DR Metlic
Chemical Resistance
As per Standard
Max. Operating Temperature
Upto 140°C
